Hoyt Carbon Spyder ZT

Our lightest compound bow outfitted with the all new patent-pending ZT Cable Guard system, Helical Flex Tuned Hollow Carbon Riser and newly-tuned AirShox suppression system, the Carbon Spyder ZT series packs a bite like no other.

Available Colors

carbon-spyder-30-xtra-colors1 carbon-spyder-30-xtra-accent

Specifications

Model	Carbon Spyder ZT 30	Carbon Spyder ZT 34	Carbon Spyder ZT Turbo	Carbon Spyder ZT LD
Limb	XTS Pro Arc	XTS Pro Arc	XTS Pro Arc	XTS 1000
Cam	Z5	Z5	Turbo	Z5
Draw Length Options for Each Cam Size	24-25.5″, 26-28″, 28-30″	25-26.5″, 27-29″, 29-31″	24.5-26″, 26-28″, 28-30″	31.5-32
FPS (ATA)	332 FPS	330 FPS	350 FPS	340 FPS
Brace Height	6³⁄₄“	6³⁄₄“	6″	7¹⁄₂“
Mass Weight	3.6 LBS.	3.8 LBS.	3.8 LBS.	4 LBS.
Axle-to-Axle	30″	34″	33″	34¹⁄₂“
Draw Weight Ranges	30-40#, 40-50#, 50-60#, 55-65#, 60-70#, 70-80#	30-40#, 40-50#, 50-60#, 55-65#, 60-70#, 70-80#	30-40#, 40-50#, 50-60#, 55-65#, 60-70#	30-40#, 40-50#, 50-60#, 55-65#, 60-70#, 70-80#

The all new Carbon Spyder ZT is available in three distinct configurations; 30 and 34-inch axle-to-axle configurations as well as the blazing fast turbo that spits out arrows at a real-world 350 feet-per-second. All feature the new patent-pending Zero Torque Cable Guard System and Hoyt’s latest technologies giving you the ultimate advantage on any hunt.

Strongest, lightest and quietest carbon riser we have ever made.
ZT Cable Guard System neutralizes unwanted torque.
Adjustable AirShox arm provides optimal damper location.
XTS Pro Arc Limbs harnessed by Pro-Lock Pocket system.

Turbo Version

Turbo Cam & 1/2, our fastest cam yet, producing blood-pumping speeds of 350 fps, “producing our fastest bow yet.”
75% let-off helps this speed cam maintain a generous valley.
Modular adjustable for easy draw length changes.

Video

Product Guide

To Order – Please contact us about your product of interest
