Hoyt Bows
Spec | Carbon Spyder ZT 30 | Carbon Spyder ZT 34 | Carbon Spyder ZT Turbo | Carbon Spyder ZT LD | Nitrum 30 | Nitrum 34 | Nitrum Turbo | Nitrum LD |
|---|---|---|---|---|---|---|---|---|
Mass Weight | 3.6 LBS | 3.8 LBS | 3.8 LBS | 4 LBS | 3.9 LBS | 4.2 LBS | 4.2 LBS | 4.4 LBS |
FPS (ATA) | 332 FPS | 330FPS | 350FPS | 340 FPS | 332 FPS | 330 FPS | 350FPS | 340 FPS |
Draw Length | 24-25.5″, 26-28″, 28-30″ | 25-26.5″, 27-29″, 29-31″ | 24.5-26″, 26-28″, 28-30″ | 31.5-32 | 24-25.5″, 26-28″, 28-30″ | 25-26.5″, 27-29″, 29-31″ | 24.5-26″, 26-28″, 28-30″ | 31.5-32″ |
Draw Weight | 30-40#, 40-50#, 50-60#, 55-65#, 60-70#, 70-80# | 30-40#, 40-50#, 50-60#, 55-65#, 60-70#, 70-80# | 30-40#, 40-50#, 50-60#, 55-65#, 60-70# | 0-40#, 40-50#, 50-60#, 55-65#, 60-70#, 70-80# | 30-40#, 40-50#, 50-60#, 55-65#, 60-70#, 70-80# | 30-40#, 40-50#, 50-60#, 55-65#, 60-70#, 70-80# | 30-40#, 40-50#, 50-60#, 55-65#, 60-70# | 30-40#, 40-50#, 50-60#, 55-65#, 60-70#, 70-80# |
Axle to Axle | 30″ | 34″ | 33″ | 34 1⁄2“ | 30″ | 34″ | 34″ | 34 1⁄2“ |
Brace Height | 6 3/4″ | 6 3/4″ | 6″ | 7 1⁄2“ | 6 3⁄4“ | 6 3⁄4“ | 6″ | 7 1⁄2“ |
Spec | Charger | Charger Long Draw | Ignite | Faktor 30 | Tribute | Ruckus | Ruckus Jr. |
|---|---|---|---|---|---|---|---|
Mass Weight | 3.8 LBS | 4 LBS | 3.6 LBS | 3.9 LBS | 4.8 LBS | 3 LBS | 3 LBS |
FPS (ATA) | 325 FPS | 327 FPS | 300 FPS | 332 FPS | 274 FPS | 258 FPS | 219 FPS |
Draw Length | 24-26.5”, 27-30” | 30.5-31” | 19-30″ | 24-25.5″, 26-28″, 28-30″ | 24-25.5″, 26-28″, 28-30″ | 15-27″ | 15-27″ |
Draw Weight | 30-40#, 40-50#, 50-60#, 55-65#, 60-70# | 30-40#, 40-50#, 50-60#, 55-65#, 60-70# | 15-70# | 30-40#, 40-50#, 50-60#, 55-65#, 60-70#, 70-80# | 30-40#, 40-50#, 50-60#, 60-70# | 15-45# | 9-29# |
Axle to Axle | 31″ | 31″ | 28″ | 30″ | 45“ | 28 5⁄8“ | 28 5⁄8“ |
Brace Height | 6 3⁄4“ | 7 1⁄2“ | 8“ | 6 3⁄4“ | 8“ | 6 5⁄8“ | 6 5⁄8“ |
